油气藏评价与开发 ›› 2025, Vol. 15 ›› Issue (3): 339-348.doi: 10.13809/j.cnki.cn32-1825/te.2025.03.001
收稿日期:
2025-05-11
发布日期:
2025-05-28
出版日期:
2025-06-26
作者简介:
郭彤楼(1965—),男,博士,正高级工程师,主要从事油气勘探研究与管理。地址:四川省成都市高新区吉泰路688号,中国石化西南油气分公司,邮政编码:610041。E-mail:tlguo@163.com
基金资助:
Received:
2025-05-11
Online:
2025-05-28
Published:
2025-06-26
摘要:
中国页岩气勘探开发历经二十年发展,已成为继美国、加拿大之外第三个实现商业开发的国家,但此前勘探开发层位仅局限于志留系龙马溪组。随着页岩气勘探理论认识的提高,近年来,二叠系、寒武系页岩相继取得了勘探突破,进一步印证了四川盆地页岩气的巨大潜力。基于对志留系龙马溪组、寒武系筇竹寺组两大海相主力层系页岩气勘探历程的回顾,总结页岩气勘探历经了研究探索(2000—2011年)、发现上产(2011—2022年)和多层突破(2022年—至今)3个阶段。深入剖析四川盆地海相页岩气勘探研究2次理论创新、思路转变的过程:① 通过对比分析中美页岩气形成条件,摒弃简单复制北美经验的思维,基于中国多期构造演化特征,突出保存条件的关键作用,实现了第一次思路转变,取得了志留系龙马溪组勘探的重大突破;②加强低有机质和无机孔特征研究,对页岩气传统富集成藏理论进行了发展和完善,建立“输导+原地”成藏模式,实现了第二次思路转变,推动了寒武系筇竹寺组勘探突破。当前,页岩气在低有机质页岩、无机孔等方面的研究突破,拓展了勘探领域和勘探深度,形成了海相页岩气多层并举的局面,展现出广阔的勘探前景。基于对志留系到寒武系页岩气勘探历程、思路转变的回顾以及重大突破带来启示的剖析,揭示了中国特色页岩气勘探之路,对未来多层系、多领域页岩气的勘探开发具有重要参考意义。
中图分类号:
GUO Tonglou. Review and reflection on shale gas development in China: From Silurian to Cambrian[J]. Petroleum Reservoir Evaluation and Development, 2025, 15(3): 339-348.
表1
四川盆地海相页岩与美国典型页岩对比(据参考文献[4-5,22-26]修改)"
层系/地区 | 龙马溪组 (焦石坝地区) | 筇竹寺组 (井研地区) | 筇竹寺组 (资阳地区) | Marcellus (阿巴拉契亚盆地) | Haynesville (密西西比盐盆地) |
---|---|---|---|---|---|
沉积背景 | 克拉通 | 凹槽西缘 | 拉张槽 | 前陆盆地 | 局限盆地 |
层序 | 1个旋回、1套页岩 | 3个旋回、3套页岩 | 4个旋回、4套页岩 | 4个旋回、4套页岩 | 4个旋回、3套页岩和 1套灰岩 |
相 | 深水陆棚 | 浅水缓坡 | 深水缓坡 | 深水陆棚 | 深水陆棚 |
镜质体反射率(Ro)/% | 2.5~3.0 | 3.3 | 3.5 | 0.8~3.6 | 2.2~2.3 |
干酪根类型 | Ⅰ-Ⅱ1型,底栖藻类 | Ⅰ型,藻类和疑源类 | Ⅰ型,藻类和疑源类 | Ⅱ型,藻类 | Ⅱ型 |
ω(TOC)/% | 3.54 | 0.45 | 2.92 | 8.55 | 3.45 |
ω(TOC)>2%的厚度/m | 24~35 | 2~3 | 22~60 | 15~45 | 60~90 |
矿物成分及 质量分数 | 钙质21.2%、硅质42.3%、长石2.6% | 钙质5.0%、硅质40.0%、长石30.0% | 钙质8.0%、硅质34.0%、长石33.0% | 钙质22.5%、硅质45.0%、长石6.0% | (钙质+硅质)55.0%、 长石10.0% |
黏土成分及 质量分数 | 伊利石41.7%,、伊/蒙混层53.5%、绿泥石3.3% | 伊利石24.0%、伊/蒙混层含量3.0%、绿泥石73.0% | 伊利石58.0%、伊/蒙混层含量9.0%、绿泥石33.0% | 伊利石25.0%、伊/蒙混层含量6.0%、绿泥石3.0% | 伊利石25.0%、伊/蒙混层含量50.0%、绿泥石20.0% |
孔隙度/% | 6~8 | 2~4 | 2~8 | 4~15 | 5~15 |
孔隙构成 | 有机质孔60.00% | 有机质孔4.59% | 有机质孔14.63% | 有机质孔为主 | 有机质孔46.00% |
脆性矿物孔8.0%、 黏土矿物孔47.0% | 脆性矿物孔30.0%、 黏土矿物孔60.0% | 脆性矿物孔34.0%、 黏土矿物孔45.0% | 脆性矿物孔19.60%、 黏土矿物孔75.50% | ||
孔体积/(ml/g) | 0.012 0 | 0.006 0 | 0.014 4 | ||
含气量/(m3/t) | 5.0~6.0 | 0.6~2.3 | 2.5~6.8 | 1.2~5.6 | 2.8~9.4 |
压力系数 | 1.89 | 1.30~1.50 | 2.08 | 0.90~1.30 | 1.60~2.10 |
