深层寒武系成岩流体演化与油气成藏——以塔里木盆地库车坳陷托探1井为例

doi:10.13809/j.cnki.cn32-1825/te.2025.03.005

油气藏评价与开发 ›› 2025, Vol. 15 ›› Issue (3): 382-393.doi: 10.13809/j.cnki.cn32-1825/te.2025.03.005

深层寒武系成岩流体演化与油气成藏——以塔里木盆地库车坳陷托探1井为例

杨宪彰¹(), 黄亚浩²(), 王斌¹, 文志刚², 周露¹, 张科¹, 何涛华², 罗涛², 陈笑², 曾强浩²

1.中国石油塔里木油田公司勘探开发研究院，新疆库尔勒 841000
2.长江大学教育部油气资源与勘探技术重点实验室，湖北武汉 434000

收稿日期:2024-10-09 发布日期:2025-05-28 出版日期:2025-06-26
通讯作者: 黄亚浩 E-mail:yangxztlm@petrochina.com.cn;hyhtr08916@163.com
作者简介:杨宪彰（1979—），男，博士，高级工程师，主要从事石油地质与沉积储层研究。地址：新疆库尔勒市石化大道26号中国石油塔里木油田公司，邮政编码：841000。E-mail：yangxztlm@petrochina.com.cn
基金资助:
国家自然科学基金项目“深层碳酸盐岩储层流体活动示踪油气差异成藏效应研究——以塔里木盆地富满油田为例”(42302154)

Oil and gas accumulation and diagenetic fluid evolution in deep Cambrian strata: A case study of well Tuotan 1, Kuqa Depression, Tarim Basin

YANG Xianzhang¹(), HUANG Yahao²(), WANG Bin¹, WEN Zhigang², ZHOU Lu¹, ZHANG Ke¹, HE Taohua², LUO Tao², CHEN Xiao², ZENG Qianghao²

1. Research Institute of Exploration and Development, PetroChina Tarim Oilfield Company, Korla, Xinjiang 841000, China
2. Key Laboratory of Exploration Technologies for Oil and Gas Resources, Ministry of Education, Yangtze University, Wuhan, Hubei 434000, China

Received:2024-10-09 Online:2025-05-28 Published:2025-06-26
Contact: HUANG Yahao E-mail:yangxztlm@petrochina.com.cn;hyhtr08916@163.com

摘要/Abstract

摘要：

塔里木盆地是深层—超深层油气勘探开发的主战场。目前塔里木盆地库车坳陷托探1井古生界寒武新层系古潜山型油气藏勘探取得重大突破。由于地层年代古老且油气藏地质构造复杂，对该区域油气成藏过程和流体演化尚未进行系统深入的研究。采用生物标志化合物分析、岩相学分析、微区原位微量元素与锶同位素分析、流体包裹体等研究方法，确定下丘里塔格组白云岩储层成脉流体来源和多期油气充注时间。结果显示，托探1井下丘里塔格组白云岩储层主要发育裂缝和溶蚀孔洞充填的2期方解石脉体，第一期方解石为深部富锶流体来源，第二期方解石脉体表现为海水来源。2期含油流体包裹体主要发育于第二期方解石脉体内部，分别为次生蓝白色荧光油包裹体和次生绿色荧光油包裹体，结合包裹体测温和单井埋藏史恢复结果显示，第一期蓝白色油包裹体成藏时间为新近系吉迪克组沉积时期（23~20 Ma），第二期绿色油包裹体成藏时间为新近系库车组沉积时期（5~3 Ma）。基于油源对比分析推测下丘里塔格组储层内2期原油来源于三叠系黄三街组和侏罗系恰克马克组湖相烃源岩的混合供烃。库车坳陷托探1井的新发现证实塔里木盆地山前古老地层中仍具有油气规模成藏条件，潜山型油气成藏成为下一步库车坳陷油气增储上产的新领域。

关键词: 流体包裹体, 油源对比, 流体演化, 寒武系, 库车坳陷

Abstract:

The Tarim Basin serves as the major area for deep and ultra-deep oil and gas exploration and development. A significant breakthrough has recently been achieved in the exploration of ancient buried hill-type oil and gas reservoirs within the Cambrian System of the Paleozoic strata in well Tuotan 1, Kuqa Depression, Tarim Basin. Due to the ancient geological age and complex reservoir geology, systematic studies on oil and gas accumulation process and fluid evolution in this area remain insufficient. In this study, methods including biomarker analysis, petrological analysis, in-situ micro-area trace element and strontium isotope analysis, and fluid inclusions were used to determine the fluid origins of vein formation and the timing of multiple-phase of oil and gas charging in the dolomite reservoirs of the Xiaqiulitage Formation. The results revealed that the dolomite reservoirs in Xiaqiulitage Formation, well Tuotan 1 primarily developed two phases of calcite veins that filled fractures and dissolution pores. The first phase of calcite originated from deep, strontium-rich fluids, while the second phase of calcite veins derived from seawater. Two phases of oil-bearing fluid inclusions were predominantly developed within the second-phase calcite veins, comprising secondary blue-white fluorescent oil inclusions and secondary green fluorescent oil inclusions. The integration of fluid inclusion thermometry with single-well burial history reconstruction revealed that the first-phase blue-white fluorescent inclusions recorded oil and gas accumulation during the deposition of the Neogene Jidike Formation (23-20 Ma), while the second-phase green oil inclusions recorded oil and gas accumulation during the deposition of the Neogene Kuqa Formation (5-3 Ma). Oil-source correlation analysis indicated that the two phases of crude oil in the reservoirs of Xiaqiulitage Formation were derived from mixed contributions of lacustrine source rocks in the Triassic Huangsanjie Formation and Jurassic Qakmak Formation. The new findings from well Tuotan 1 in Kuqa Depression demonstrate that ancient strata in the foreland region of the Tarim Basin still retain favorable conditions for large-scale oil and gas accumulation, making buried hill-type oil and gas reservoirs a promising frontier for increasing reserves and production in Kuqa Depression.

Key words: fluid inclusion, oil-source correlation, fluid evolution, Cambrian, Kuqa Depression

中图分类号:

TE122

杨宪彰,黄亚浩,王斌, 等. 深层寒武系成岩流体演化与油气成藏——以塔里木盆地库车坳陷托探1井为例[J]. 油气藏评价与开发, 2025, 15(3): 382-393.

YANG Xianzhang,HUANG Yahao,WANG Bin, et al. Oil and gas accumulation and diagenetic fluid evolution in deep Cambrian strata: A case study of well Tuotan 1, Kuqa Depression, Tarim Basin[J]. Petroleum Reservoir Evaluation and Development, 2025, 15(3): 382-393.

图/表 12

图1

图2

图3

图4

图5

图6

图7

图8

图9

图10

图11

图12

参考文献 34

1	王清华, 杨海军, 蔡振忠, 等. 塔里木盆地库车南斜坡托探1井油气勘探重大突破及意义[J]. 中国石油勘探, 2023, 28(5): 28-42.
	WANG Qinghua, YANG Haijun, CAI Zhenzhong, et al. Major breakthrough and significance of petroleum exploration in Well Tuotan 1 on the south slope of Kuqa Depression, Tarim Basin[J]. China Petroleum Exploration, 2023, 28(5): 28-42.
2	胡来东, 张志林, 徐雷良, 等. 塔里木盆地顺北地区碳酸盐岩断控储集体连通性量化表征[J]. 世界石油工业, 2024, 31(6): 30-37.
	HU Laidong, ZHANG Zhilin, XU Leiliang, et al. Internal connectivity quantitative characterization of fault-controlled grid reservoirs in Shunbei area, Tarim Basin[J]. World Petroleum Industry, 2024, 31(6): 30-37.
3	凡闪, 卢玉红, 李玲, 等. 塔里木盆地库车坳陷吐格尔明及周缘地区三叠系—侏罗系烃源岩地球化学特征、分布规律与油气地质意义[J]. 天然气地球科学, 2022, 33(12): 2074-2086.
	FAN Shan, LU Yuhong, LI Ling, et al. Geochemical characteristics, distribution and petroleum geological significance of Triassic-Jurassic source rocks in the Tugeerming and surrounding areas of Kuqa Depression, Tarim Basin[J]. Natural Gas Geoscience, 2022, 33(12): 2074-2086.
4	马永生, 蔡勋育, 赵培荣, 等. 中国陆相页岩油地质特征与勘探实践[J]. 地质学报, 2022, 96(1): 155-171.
	MA Yongsheng, CAI Xunyu, ZHAO Peirong, et al. Geological characteristics and exploration practices of continental shale oil in China[J]. Acta Geologica Sinica, 2022, 96(1): 155-171.
5	代振龙, 徐仕琪, 赵建邦, 等. 塔里木盆地东南缘瓦石峡凹陷侏罗系烃源岩地球化学特征及油气意义[J]. 新疆地质, 2023, 41(S1): 57.
	DAI Zhenlong, XU Shiqi, ZHAO Jianbang, et al. Geochemical characteristics and hydrocarbon significance of Jurassic source rocks in Washixia sag, southeastern margin of Tarim Basin[J]. Xinjiang Geology, 2023, 41(S1): 57.
6	郑民, 李建忠, 吴晓智, 等. 我国主要含油气盆地油气资源潜力及未来重点勘探领域[J]. 地球科学, 2019, 44(3): 833-847.
	ZHENG Min, LI Jianzhong, WU Xiaozhi, et al. Potential of oil and natural gas resources of main hydrocarbon-bearing basins and key exploration fields in China[J]. Earth Science, 2019, 44(3): 833-847.
7	张恩泽, 张立强, 严一鸣, 等. 库车坳陷东部下侏罗统阿合组重矿物特征及物源分析[J]. 中国科技论文, 2023, 18(9): 1021-1027.
	ZHANG Enze, ZHANG Liqiang, YAN Yiming, et al. Heavy mineral characteristics and provenance analysis of Lower Jurassic Ahe formation in eastern Kuqa depression[J]. China Sciencepaper, 2023, 18(9): 1021-1027.
8	张昊, 吕修祥, 王晓雪, 等. 库车前陆盆地南斜坡西段油气成藏过程研究[J]. 石油科学通报, 2025, 10(1): 35-50.
	ZHANG Hao, Xiuxiang LYU, WANG Xiaoxue, et al. Study on hydrocarbon accumulation process in the western section of south slope of Kuqa foreland basin[J]. Petroleum Science Bulletin, 2025, 10(1): 35-50.
9	李贤庆, 周强, 汪为孝, 等. 库车坳陷三叠-侏罗纪烃源岩生气特征与生气模式[J]. 煤田地质与勘探, 2007, 35(6): 18-22.
	LI Xianqing, ZHOU Qiang, WANG Weixiao, et al. Characteristics and models of gaseous hydrocarbon generation from Triassic-Jurassic source rocks in Kuqa Depression[J]. Coal Geology & Exploration, 2007, 35(6): 18-22.
10	王清华. 塔北西部喀拉玉尔衮构造带上寒武统下丘里塔格组油气勘探突破及意义[J]. 石油学报, 2024, 45(4): 615-628.
	WANG Qinghua. Break through and significance of oil and gas exploration of Upper Cambrian Xiaqiulitage Formation in Kalayuergun structural belt, western Tabei uplift[J]. Acta Petrolei Sinica, 2024, 45(4): 615-628.
11	GOLDSTEIN R H. Reequilibration of fluid inclusions in low-temperature calcium-carbonate cement[J]. Geology, 1986, 14(9): 792-795.
12	张玉强, 李凤春, 张伟. 激光剥蚀电感耦合等离子体联用条件优化及其应用[J]. 山东国土资源, 2018, 34(9): 92-96.
	ZHANG Yuqiang, LI Fengchun, ZHANG Wei. Optimization and application of combined condition of laser ablation inductively coupled plasma[J]. Shandong Land and Resources, 2018, 34(9): 92-96.
13	宋嘉琦, 肖晖. 川中古隆起震旦系灯二段流体包裹体特征与成藏过程[J]. 断块油气田, 2024, 31(5): 762-770.
	SONG Jiaqi, XIAO Hui. Characteristics of fluid inclusions and accumulation process in the second Member of Dengying Formation of the Sinian in central Sichuan paleo-uplift[J]. Fault-Block Oil & Gas Field, 2024, 31(5): 762-770.
14	梁万乐, 李贤庆, 魏强, 等. 库车坳陷北部山前带中生界烃源岩有机岩石学[J]. 现代地质, 2018, 32(6): 1137-1149.
	LIANG Wanle, LI Xianqing, WEI Qiang, et al. Organic petrology of Mesozoic source rocks in the northern piedmont zone of the kuqa depression[J]. Geoscience, 2018, 32(6): 1137-1149.
15	朱莲花, 徐珊. 塔里木盆地顺北地区1号、5号断裂带奥陶系原油地球化学特征及控藏因素[J]. 世界石油工业, 2024, 31(4): 58-68.
	ZHU Lianhua, XU Shan. Geochemical characteristics and reservoir controlling factors of Ordovician ultra-deep crude oil in No. 1 and No. 5 fault zones in Shunbei area[J]. World Petroleum Industry, 2024, 31(4): 58-68.
16	李二庭, 王汇彤, 王剑, 等. 准噶尔盆地乌夏地区生物降解原油中饱和烃组成解析[J]. 天然气地球科学, 2020, 31(4): 462-470.
	LI Erting, WANG Huitong, WANG Jian, et al. Study on composition of saturated hydrocarbon complex mixtures in biodegraded crude oil from Wuxia area, Junggar Basin[J]. Natural Gas Geoscience, 2020, 31(4): 462-470.
17	黄亚浩, 汪如军, 文志刚, 等. 塔里木盆地富满油田深层—超深层油气成藏过程[J]. 石油学报, 2024, 45(6): 947-960.
	HUANG Yahao, WANG Rujun, WEN Zhigang, et al. Hydrocarbon accumulation process of the deep to ultra deep reservoirs in Fuman oilfield, Tarim Basin[J]. Acta Petrolei Sinica, 2024, 45(6): 947-960.
18	陈俊林, 黄亚浩, 郭小文, 等. 方解石脉体形成时间与流体来源及其地质意义: 以苏北盆地黄桥地区三叠系青龙组碳酸盐岩储层为例[J]. 地质科技通报, 2024, 43(3): 157⁃169.
	CHEN Junlin, HUANG Yahao, GUO Xiaowen, et al. Formation time and fluid source of calcite veins and geological significance: An example from the Triassic Qinglong Formation carbonate reservoirs in the Huangqiao area, Subei Basin[J]. Bulletin of Geological Science and Technology, 2024, 43(3): 157⁃169.
19	汪紫菱, 徐新德, 游君君, 等. 烃类包裹体荧光光谱技术在乌石凹陷油气成藏期次研究中的应用[J]. 中国海上油气, 2022, 34(5): 46-55.
	WANG Ziling, XU Xinde, YOU Junjun, et al. Application of fluorescence spectroscopy of hydrocarbon inclusions in the study of hydrocarbon accumulation stages in Wushi sag[J]. China Offshore Oil and Gas, 2022, 34(5): 46-55.
20	FILDANI A, HANSON A D, CHEN Z, et al. Geochemical characteristics of oil and source rocks and implications for petroleum systems, Talara basin, northwest Peru[J]. AAPG bulletin, 2005, 89(11): 1519-1545.
21	朱光有, 胡剑风, 陈永权, 等. 塔里木盆地轮探1井下寒武统玉尔吐斯组烃源岩地球化学特征与形成环境[J]. 地质学报, 2022, 96(6): 2116-2130.
	ZHU Guangyou, HU Jianfeng, CHEN Yongquan, et al. Geochemical characteristics and formation environment of source rock of the Lower Cambrian Yuertusi Formation in well Luntan 1 in Tarim basin[J]. Acta Geologica Sinica, 2022, 96(6): 2116-2130.
22	HE T H, LI W H, LU S F, et al. Quantitatively unmixing method for complex mixed oil based on its fractions carbon isotopes: A case from the Tarim Basin, NW China[J]. Petroleum Science, 2023, 20(1): 102-113.
23	王柏然, 黄志龙, 肖冬生, 等. 吐哈盆地台北凹陷下侏罗统原油地球化学特征及油—源精细对比[J]. Natural Gas Geoscience, 2024, 35(1).
	WANG Boran, HUANG Zhilong, XIAO Dongsheng, et al. Geochemical characteristics of the Lower Jurassic hydrocarbon and fine oil-source correlation in Taibei Sag, Turpan-Hami Basin[J]. Natural Gas Geoscience, 2024, 35(1): 164-175
24	CAO Y, WANG Q, ZOU H, et al. Genesis types and distribution laws of crude oil in Langgu sag[J]. Acta Petrolei Sinica, 2017, 38(11): 1263.
25	HUANG H, ZHANG S, GU Y, et al. Impacts of source input and secondary alteration on the extended tricyclic terpane ratio: A case study from Palaeozoic sourced oils and condensates in the Tarim Basin, NW China[J]. Organic Geochemistry, 2017, 112: 158-169.
26	黄思静, 卿海若, 胡作维, 等. 川东三叠系飞仙关组碳酸盐岩的阴极发光特征与成岩作用[J]. 地球科学, 2008, 33(1): 26-34.
	HUANG Sijing, QING Hairuo, HU Zuowei, et al. Cathodoluminescence and diagenesis of the carbonate rocks in Feixianguan formation of Triassic, eastern Sichuan basin of China[J]. Earth Science, 2008, 33(1): 26-34.
27	肖雪薇. 中国南方湘西、鄂西长阳地区下古生界牛蹄塘组流体演化及页岩气保存条件分析[D]. 武汉: 中国地质大学, 2023.
	XIAO Xuewei. Fluid evolution and shale gas preservation conditions analysis in the lower Paleozoic niutitang formation of the western Hunan and the western Hubei Changyang areas, Southern China[D]. Wuhan: China University of Geosciences, 2023.
28	胡文瑄, 陈琪, 王小林, 等. 白云岩储层形成演化过程中不同流体作用的稀土元素判别模式[J]. 石油与天然气地质, 2010, 31(6): 810-818.
	HU Wenxuan, CHEN Qi, WANG Xiaolin, et al. REE models for the discrimination of fluids in the formation and evolution of dolomite reservoirs[J]. Oil & Gas Geology, 2010, 31(6): 810-818.
29	杨洋, 周跃飞, 骆少勇, 等. 碳酸盐岩中锰与铈分布相关性对沉积氧化还原条件的指示[J]. 合肥工业大学学报(自然科学版), 2019, 42(12): 1687-1694.
	YANG Yang, ZHOU Yuefei, LUO Shaoyong, et al. Distribution relationship between Mn and Ce in carbonates as an indicator on sedimentary redox condition[J]. Journal of Hefei University of Technology (Natural Science), 2019, 42(12): 1687-1694.
30	李超, 罗涛, 黄亚浩, 等. 苏北盆地高邮凹陷花页1井古近系阜宁组裂缝脉体流体演化及其对页岩油充注过程的指示意义[J]. 石油实验地质, 2024, 46(2): 228-237.
	LI Chao, LUO Tao, HUANG Yahao, et al. Fluid evolution of fracture veins of Paleogene Funing Formation in well HY1 in Subei Basin and implications for shale oil filling[J]. Petroleum Geology & Experiment, 2024, 46(2): 228-237.
31	胡作伟, 李云, 李北康, 等. 显生宙以来海水锶同位素组成研究的回顾与进展[J]. 地球科学进展, 2015, 30(1): 37-49.
	HU Zuowei, LI Yun, LI Beikang, et al. An overview of the strontium isotopic composition of phanerozoic seawater[J]. Advances in Earth Science, 2015, 30(1): 37-49.
32	MCARTHUR J M, HOWARTH R J, BAILEY T R. Strontium isotope stratigraphy: LOWESS version 3: Best fit to the marine Sr-isotope curve for 0~509 Ma and accompanying look-up table for deriving numerical age[J]. The Journal of Geology, 2001, 109(2): 155-170.
33	罗富文, 柳少波, 卓勤功, 等. 库车坳陷秋里塔格构造带中东段油气充注期次及成藏模式[J]. 东北石油大学学报, 2024, 48(1): 26-38.
	LUO Fuwen, LIU Shaobo, ZHUO Qingong, et al. Hydrocarbon charging stage and accumulation model in the middle-east section of Qiulitage Structural Belt, Kuqa Depression[J]. Journal of Northeast Petroleum University, 2024, 48(1): 26-38.
34	桂丽黎, 卓勤功, 鲁雪松, 等. 基于原位方解石U-Pb定年与包裹体分析技术恢复储集层成岩-成藏过程: 以准噶尔盆地南缘高泉地区白垩系清水河组为例[J]. 石油勘探与开发, 2023, 50(6): 1209-1220.
	GUI Lili, ZHUO Qingong, LU Xuesong, et al. Restoration of reservoir diagenesis and hydrocarbon accumulation process by calcite in-situ U-Pb dating and fluid inclusion analysis: A case study on Cretaceous Qingshuihe Formation in Gaoquan, southern Junggar Basin, NW China[J]. Petroleum Exploration and Development, 2023, 50(6): 1209-1220.
