注入介质和注入方式对致密油提高采收程度影响实验研究——以大庆扶余储层为例

doi:10.13809/j.cnki.cn32-1825/te.2025.04.003

摘要/Abstract

摘要：

致密油藏作为目前中国油气藏开发重点，因储层物性差、连通性不佳、非均质性强的特点导致其开采难度大。在致密油藏开采过程中，不同注入介质和注采方式对致密油藏开采的机理及提采效果不明确，从而严重制约了致密油藏的高效开采。以中国石油大庆油田扶余储层为例，开展不同注入介质（CO₂、活性剂）及不同注入方式（驱替、吞吐、气水交替）的地层岩心动态注入室内实验，研究不同注入介质及注入方式对致密油藏的提采机理及提采效果。结果发现：气水交替驱与CO₂气驱相比，地下原油采出程度提高了4.14%，与活性剂驱相比，地下原油采出程度提高了15.38%；气水交替吞吐与CO₂吞吐相比，地下原油采出程度提高了0.54%，与活性剂吞吐相比，地下原油采出程度提高了5.09%。建立驱油优势通道后的驱替比吞吐具有更大的波及体积与洗油效率，且气水交替注入较单一介质注入有效地降低了流体窜流，增大了对细小孔隙的清扫。由于CO₂注入对地层原油的降黏及溶解气驱效果较好，CO₂注入采出程度高于活性剂注入。同等注采条件下，低黏度原油的采出程度高于高黏度原油，黏度的增大显著增大了渗流阻力。研究得出了不同注入介质及不同注入方式对致密油藏开发的提采程度差异，为致密油藏进一步高效开发提供实验及理论支持。

关键词: 致密油藏, 活性剂, 驱替, 吞吐, 气水交替, 提高采出程度

Abstract:

Tight oil reservoirs, as a key focus in China’s current oil and gas development, present significant exploration challenges due to their poor physical properties, limited connectivity, and strong heterogeneity. During the exploration of tight oil reservoirs, the influence of different injection media and production methods on recovery mechanisms and performance remains unclear, severely restricting their efficient exploration of these reservoirs. Taking the Fuyu reservoir in the Daqing oilfield of PetroChina as a case study, laboratory experiments involving dynamic core injection were conducted using various injection media (CO₂ and surfactants) and methods (displacement, huff-n-puff, and gas-water alternating injection) to investigate their effects on oil recovery mechanisms and efficiency in tight reservoirs. The results indicated that gas-water alternating displacement improved underground oil recovery by 4.14% compared to CO₂ displacement and by 15.38% compared to surfactant displacement. Similarly, gas-water alternating huff-n-puff increased oil recovery by 0.54% over CO₂ huff-and-puff and by 5.09% compared to surfactant huff-n-puff. Displacement methods, after forming preferential oil flow channels, exhibited larger sweep volumes and higher oil displacement efficiency than huff-and-puff methods. Moreover, gas-water alternating injection effectively reduced fluid channeling compared to single-media injection and enhanced the sweep of fine pore spaces. Due to CO₂’s superior viscosity reduction and dissolved gas drive effects on reservoir crude oil, CO₂ injection achieved higher recovery than surfactant injection. Under identical injection-production conditions, low-viscosity crude oil exhibited a higher recovery compared to high-viscosity crude oil, as increased viscosity significantly raised flow resistance. The study reveals the differences in recovery performance associated with various injection media and methods, providing experimental evidence and theoretical support for the efficient development of tight oil reservoirs.

Key words: tight oil reservoir, surfactant, displacement, huff-n-puff, gas-water alternating injection, enhanced oil recovery

中图分类号:

TE357

汤勇,袁晨刚,何佑伟, 等. 注入介质和注入方式对致密油提高采收程度影响实验研究——以大庆扶余储层为例[J]. 油气藏评价与开发, 2025, 15(4): 554-563.

TANG Yong,YUAN Chengang,HE Youwei, et al. Experimental study on injection media and methods for enhanced oil recovery in tight oil reservoirs: A case study of Fuyu reservoir in Daqing[J]. Petroleum Reservoir Evaluation and Development, 2025, 15(4): 554-563.

图/表 10

表1

表2

表3

图1

图2

图3

图4

图5

图6

图7

参考文献 42

[1]	蒙晓灵, 王得志, 邢雪杰, 等. 致密气藏砂岩空间发育模式对水平井产能的影响[J]. 天然气勘探与开发, 2023, 46(2): 103-109.
	MENG Xiaoling, WANG Dezhi, XING Xuejie, et al. Influence of sandbody development pattern on horizontal-well productivity in tight gas reservoirs[J]. Natural Gas Exploration and Development, 2023, 46(2): 103-109.
[2]	周克明, 袁小玲, 刘婷芝, 等. 四川盆地公山庙油田中侏罗统沙溪庙组一段致密油藏流体渗流特征[J]. 天然气勘探与开发, 2024, 47(1): 73-82.
	ZHOU Keming, YUAN Xiaoling, LIU Tingzhi, et al. Fluid flow behaviors in tight reservoirs of the Middle Jurassic Shaximiao 1 Member, Gongshanmiao oilfield, Sichuan Basin[J]. Natural Gas Exploration and Development, 2024, 47(1): 73-82.
[3]	沈童, 卢文涛, 郑爱维, 等. 四川盆地复兴地区侏罗系陆相页岩油可采储量评价方法[J]. 天然气勘探与开发, 2024, 47(5): 39-47.
	SHEN Tong, LU Wentao, ZHENG Aiwei, et al. An integrated method for estimating recoverable reserves of Jurassic continental shale oil in Fuxing area, Sichuan Basin[J]. Natural Gas Exploration and Development, 2024, 47(5): 39-47.
[4]	李书恒, 王永宏, 邓秀芹, 等. 鄂尔多斯盆地长6和长8段致密油储层驱渗特征研究[J]. 非常规油气, 2024, 11(2): 80-91.
	LI Shuheng, WANG Yonghong, DENG Xiuqin, et al. Study on water displacement and imbibition features of Chang6 & Chang8 tight oil reservoir in Ordos Basin[J]. Unconventional Oil & Gas, 2024, 11(2): 80-91.
[5]	赵航, 罗腾跃, 贺沛, 等. 鄂尔多斯盆地南部山西组致密储层的分形特征及其影响因素分析[J]. 非常规油气, 2024, 11(2): 37-45.
	ZHAO Hang, LUO Tengyue, HE Pei, et al. Fractal characteristics and influencing factors of tight reservoirs in Shanxi Formation in southern Ordos Basin[J]. Unconventional Oil & Gas, 2024, 11(2): 37-45.
[6]	康毅力, 田键, 罗平亚, 等. 致密油藏提高采收率技术瓶颈与发展策略[J]. 石油学报, 2020, 41(4): 467-477.
	KANG Yili, TIAN Jian, LUO Pingya, et al. Technical bottlenecks and development strategies of enhancing recovery for tight oil reservoirs [J]. Acta Petrolei Sinica, 2020, 41(4): 467-477.
[7]	焦方正. 非常规油气之“非常规”再认识[J]. 石油勘探与开发, 2019, 46(5): 803-810.
	Fangzheng JAO. Re-recognition of “unconventional” in unconventional oil and gas[J]. Petroleum Exploration and Development, 2019, 46(5): 803-810.
[8]	赵向原, 吕文雅, 王策, 等. 低渗透砂岩油藏注水诱导裂缝发育的主控因素: 以鄂尔多斯盆地安塞油田W区长6油藏为例[J]. 石油与天然气地质, 2020, 41(3): 586-595.
	ZHAO Xiangyuan, Wenya LYU, WANG Ce, et al. Major factors controlling waterflooding-induced fracture development in low-permeability reservoirs: A case study of Chang 6 reservoir in W block in Ansai oilfield, Ordos Basin[J]. Oil & Gas Geology, 2020, 41(3): 586-595.
[9]	李童, 龙安林, 刘波, 等. 低渗透砂岩油藏隔夹层注气突破压力及注气开发策略: 以柴达木盆地尕斯库勒油田E31油藏为例[J]. 石油学报, 2021, 42(10): 1364-1372.
	LI Tong, LONG Anli, LIU Bo, et al. Breakthrough pressure and development strategy for gas injection in interlayers in low-permeability sandstone reservoirs: A case study of the Gasikule E31 reservoir, Qaidam Basin[J]. Acta Petrolei Sinica, 2021, 42(10): 1364-1372.
[10]	李俊键, 姜汉桥, 周代余, 等. 古油藏低矿化度水驱微观剩余油动用机理实验研究[J]. 油气地质与采收率, 2018, 25(5): 104-109.
	LI Junjian, JIANG Hanqiao, ZHOU Daiyu, et al. Experimental study on the microscopic displacement mechanism of remaining oil by low salinity water flooding in the paleo-oil reservoir[J]. Petroleum Geology and Recovery Efficiency, 2018, 25(5): 104-109.
[11]	NGUYEN D, WANG D, OLADAPO A, et al. Evaluation of surfactants for oil recovery potential in shale reservoirs[C]//paper SPE 169085-MS presented at the SPE Improved Oil Recovery Symposium, Tulsa, Oklahoma, USA, April 2014.
[12]	李宾飞, 郑磊, 柏浩, 等. 裂缝性致密油藏CO₂吞吐开采孔隙原油动用特征[J]. 中国石油大学学报(自然科学版), 2023, 47(4): 119-127.
	LI Binfei, ZHENG Lei, BAI Hao, et al. Pore scale crude oil production characteristics during CO₂ huff and puff in fractured tight reservoirs[J]. Journal of China University of Petroleum (Edition of Natural Science), 2023, 47(4): 119-127.
[13]	CHABACK J J, WILLIAMS M L. Px behavior of a rich-gas condensate in admixture with CO₂ and (N₂+ CO₂)[J]. SPE Reservoir Engineering, 1994, 9(1): 44-50.
[14]	HAMZA A, HUSSEIN I A, AL-MARRI M J, et al. CO₂ enhanced gas recovery and sequestration in depleted gas reservoirs: A review[J]. Journal of Petroleum Science and Engineering, 2021, 196: 107685.
[15]	FAREED A G, KHOJA A H, DE FELICE F, et al. Underground geological sequestration of carbon dioxide(CO₂) and its effect on possible enhanced gas and oil recovery in a fractured reservoir of Eastern Potwar Basin, Pakistan[J]. Science of The Total Environment, 2023, 905: 167124.
[16]	WANG X, LI S, TONG B, et al. Multiscale wettability characterization under CO₂ geological storage conditions: A review[J]. Renewable and Sustainable Energy Reviews, 2024, 189: 113956.
[17]	WANG W, WEN J, WANG C, et al. Current status and development trends of CO₂ storage with enhanced natural gas recovery(CS-EGR) [J]. Fuel, 2023, 349: 128555.
[18]	TODD H B, EVANS J G. Improved oil recovery IOR pilot projects in the Bakken formation[C]//Paper SPE-180270-MS presented at the SPE Low Perm Symposium, Denver, Colorado, USA, May 2016.
[19]	周拓, 刘学伟, 杨正明, 等. 二氧化碳驱储集层堵塞机理实验分析[J]. 石油勘探与开发, 2015, 42(4): 502-506.
	ZHOU Tuo, LIU Xuewei, YANG Zhengming, et al. Experimental analysis on reservoir blockage mechanism for CO₂ flooding[J]. Petroleum Exploration and Development, 2015, 42(4): 502-506.
[20]	蒲春生, 康少飞, 蒲景阳, 等. 中国致密油藏水平井注水吞吐技术进展与发展趋势[J]. 石油学报, 2023, 44(1): 188-206.
	PU Chunsheng, KANG Shaofei, PU Jingyang, et al. Progress and development trend of water huff-n-puff technology for horizontal wells in tight oil reservoirs in China[J]. Acta Petrolei Sinica, 2023, 44(1): 188-206.
[21]	王鹏, 王明, 张佳磊, 等. 致密油水平井小型注水吞吐技术研究[J]. 石油化工应用, 2023, 42(7): 55-59.
	WANG Peng, WANG Ming, ZHANG Jialei, et al. Research on small-scale water injection huff and puff technology for horizontal well of tight oil [J]. Petrochemical industry Application, 2023, 42(7): 55-59.
[22]	王栋, 展转盈, 马彬. 致密油储层注水吞吐动态渗吸特征及影响因素[J]. 西安石油大学学报(自然科学版), 2021, 36(2): 50-56.
	WANG Dong, ZHAN Zhuanying, MA Bin. Dynamic imbibition characteristics and influencing factors of water injection huff-puff in tight oil reservoir[J]. Journal of Xi’an Shiyou University (Natural Science Edition), 2021, 36(2): 50-56.
[23]	樊建明, 王冲, 屈雪峰, 等. 鄂尔多斯盆地致密油水平井注水吞吐开发实践: 以延长组长7油层组为例[J]. 石油学报, 2019, 40(6): 706-715.
	FAN Jianming, WANG Chong, QU Xuefeng, et al. Development and practice of water flooding hulf-puff in tight oil horizontal well Ordos Basin: A case study of Yanchang Formation Chang 7 oil layer[J]. Acta Petrolei Sinica, 2019, 40(6): 706-715.
[24]	李鹏程, 张煜培, 章倩倩, 等. 定边地区致密油动态吞吐渗吸驱油技术研究[J]. 石油化工应用, 2022, 41(10): 24-27.
	LI Pengcheng, ZHANG Yupei, ZHANG Qianqian, et al. Study on dynamic huff and puff imbibition flooding technology for tight oil in Ding bian area[J]. Petrochemical Industry Application, 2022, 41(10): 24-27.
[25]	侯向前, 张福祥, 胡广军, 等. 渗吸驱油用表面活性剂研究现状及展望[J]. 化学工程师, 2024, 38(1): 70-74.
	HOU Xiangqian, ZHANG Fuxiang, HU Guangjun, et al. Research status and prospect of surfacants for imbibition flooding[J]. Chemical Engineer, 2024, 38(1): 70-74.
[26]	王浩栋, 展转盈, 安泽鹏. 低渗致密油藏开发技术的研究进展[J]. 当代化工研究, 2023, (20): 29-31.
	WANG Haodong, ZHAN Zhuanying, AN Zepeng. Research progress on development technology of low permeability tight reservoir[J]. Modern Chemical Research, 2023, (20): 29-31.
[27]	王威, 张云宝, 王楠, 等. 表面活性剂驱油机理分析及现状研究[J]. 当代化工, 2019, 48(8): 1850-1852.
	WANG Wei, ZHANG Yunbao, WANG Nan, et al. Mechanism analysis and current situation of surfactant flooding[J]. Contemporary Chemical Industry, 2019, 48(8): 1850-1852.
[28]	王姗姗, 冯奇, 康晓东, 等. 表面活性剂对低渗透油藏自发渗吸影响研究[J]. 当代化工, 2020, 49(10): 2175-2180.
	WANG Shanshan, FENG Qi, KANG Xiaodong, et al. Effect of surfactants on the imbibition property of low-permeability reservoirs[J]. Contemporary Chemical Industry, 2020, 49(10): 2175-2180.
[29]	康万利, 赵晗, 邵硕, 等. 表面活性剂复配提高超低渗油藏渗吸采收率[J]. 油田化学, 2019, 36(4): 667-671.
	KANG Wanli, ZHAO Han, SHAO Shuo, et al. Surfactant combination for improving the imbibition recovery of ultra-low permeability reservoir[J]. Oilfield Chemistry, 2019, 36(4): 667-671.
[30]	李阳, 黄文欢, 金勇, 等. “双碳”愿景下中国石化不同油藏类型CO₂驱提高采收率技术发展与应用[J]. 油气藏评价与开发, 2021, 11(6): 793-804.
	LI Yang, HUANG Wenhuan, JIN Yong, et al. Different reservoir types of CO₂, flooding in Sinopec EOR technology development and application under “dual carbon” vision[J]. Petroleum Reservoir Evaluation and Development, 2021, 11(6): 793-804.
[31]	石磊. 致密砂岩油藏CO₂吞吐沥青质沉积对储层的伤害特征[J]. 油田化学, 2022, 39(2): 343-348.
	SHI Lei. Damage characteristics of asphaltene deposition during CO₂ huff and puff in tight sandstone reservoir[J]. Oilfield Chemistry, 2022, 39(2): 343-348.
[32]	孙宜丽. 注CO₂改善河南双河油田低渗储层注水能力机理研究[J]. 油气藏评价与开发, 2024, 14(1): 55-63.
	SUN Yili. Mechanism of CO₂ injection to improve the water injection capacity of low permeability reservoir in Shuanghe Oilfield in Henan[J]. Petroleum Reservoir Evaluation and Development, 2024, 14(1): 55-63.
[33]	赵坤, 李泽阳, 刘娟丽, 等. 吉木萨尔页岩油井区CO₂前置压裂工艺参数优化及现场实践[J]. 油气藏评价与开发, 2024, 14(1): 83-90.
	ZHAO Kun, LI Zeyang, LIU Juanli, et al. Parameter optimization and field practice of CO₂ pre-fracturing process in Jimsar shale oil block[J]. Petroleum Reservoir Evaluation and Development, 2024, 14(1): 83-90.
[34]	朱浩楠, 曹成, 张烈辉, 等. CO₂驱气提高采收率机理及发展方向[J]. 油气藏评价与开发, 2024, 14(6): 975-980.
	ZHU Haonan, CAO Cheng, ZHANG Liehui, et al. Mechanism and development direction of CO₂-EGR[J]. Petroleum Reservoir Evaluation and Development, 2024, 14(6): 975-980.
[35]	秦正山, 罗沛, 刘先山, 等. 气水交替驱提高采收率室内实验研究[J]. 石油化工高等学校学报, 2019, 32(6): 52-56.
	QIN Zhengshan, LUO Pei, LIU Xianshan, et al. EOR laboratory experimental study of WAG flooding[J]. Journal of Petrochemical Universities, 2019, 32(6): 52-56.
[36]	魏峰, 李跃林, 马帅, 等. 涠洲12-1油田天然气-水控制气窜实验研究[J]. 重庆科技学院学报(自然科学版), 2021, 23(2): 12-15.
	WEI Feng, LI Yuelin, MA Shuai, et al. Experimental study on gas-water control gas channeling in Weizhou 12-1 Oilfield[J]. Journal of Chongqing University of Science and Technology (Natural Sciences Edition), 2021, 23(2): 12-15.
[37]	胡伟, 吕成远, 王锐, 等. 水驱油藏注CO₂非混相驱油机理及剩余油分布特征[J]. 油气地质与采收率, 2017, 24(5): 99-105.
	HU Wei, Chengyuan LYU, WANG Rui, et al. Mechanism of CO₂ immiscible flooding and distribution of remaining oil in water drive oil reservoir[J]. Petroleum Geology and Recovery Efficiency, 2017, 24(5): 99-105.
[38]	ZHAO F, WANG P, HUANG S, et al. Performance and applicable limits of multi-stage gas channeling control system for CO₂ flooding in ultra-low permeability reservoirs[J]. Journal of Petroleum Science and Engineering, 2020, 192: 107336.
[39]	胡泽根, 马宇奔, 李明峰, 等. 致密油提高采收率技术研究进展[J]. 石油化工应用, 2023, 42(3): 5-11.
	HU Zegen, MA Yuben, LI Mingfeng, et al. Research progress on enhanced oil recovery technology of tight oil[J]. Petrochemical Industry Application, 2023, 42(3): 5-11.
[40]	贺东旭. 低渗致密油藏重复压裂用渗吸液的研究与应用[J]. 石油与天然气化工, 2023, 52(2): 99-103.
	HE Dongxu. Research and application of re-fracturing with imbibition technology in low permeability and tight oil reservoir[J]. Chemical Engineering of Oil & Gas, 2023, 52(2): 99-103.
[41]	高雅洁, 郭富凤, 邓清源, 等. 四川盆地致密气藏开发指标评价方法[J]. 天然气勘探与开发, 2024, 47(5): 29-38.
	GAO Yajie, GUO Fufeng, DENG Qingyuan, et al. An evaluation method for development indexes in tight gas reservoirs of Sichuan Basin and its application[J]. Natural Gas Exploration and Development, 2024, 47(5): 29-38.
[42]	许宁, 满安静, 徐萍, 等. 非常规油藏补能提采开发方式研究进展及路径优选[J]. 中外能源, 2023, 28(8): 38-46.
	XU Ning, MAN Anjing, XU Ping, et al. Research progress and path optimization of enhanced oil recovery by energy supplement in unconventional reservoirs[J]. Sino-global Energy, 2023, 28(8): 38-46.

井号	地层压力/MPa	饱和压力/MPa	原始气油比	地层温度/℃	体积系数	原油密度/(g/cm³)	原油黏度/(mPa·s)	溶解系数/[(m³/m³)/MPa]	CO₂最小混相压力/MPa
塔21-4外扩区块	18.90	7.58	31.45	98.0	1.15	0.768	2.53	4.052	32.12
葡483-481区块	15.64	4.09	14.84	85.4	1.09	0.808	5.03	3.630	31.30

岩心编号	长度/cm	直径/cm	渗透率/10^-3μm²	孔隙度/%	孔隙体积/cm³
3-1	8.16	2.5	1.20	12.37	4.99
9-1	8.20	2.5	1.02	16.15	6.50
5-4	6.20	2.5	0.98	11.14	3.39
7-3	8.25	2.5	0.92	12.34	5.08

岩心编号	长度/cm	直径/cm	渗透率/10^-3 μm²	孔隙度/%	孔隙体积/cm³
43-3	8.06	2.5	0.85	14.37	2.348
26-4	7.91	2.5	1.03	11.15	2.230
47-1	7.90	2.5	1.20	12.14	2.242
28-1	8.20	2.5	1.18	11.34	3.577
